Visual network microphone D-7902
1. Professional paging host appearance, desktop design, using a 7-inch high-definition IPS screen with a resolution of 1280 * 720, fully virtual buttons and physical buttons, with a beautiful and elegant appearance; 2. Adopting industrial g...
Application：
Park, supermarket, elevator visual intercom, outdoor emergency assistance
Consult Now
1. Professional paging host appearance, desktop design, using a 7-inch high-definition IPS screen with a resolution of 1280 * 720, fully virtual buttons and physical buttons, with a beautiful and elegant appearance;
2. Adopting industrial grade 4-core ARM Cortex A17 chip with a main frequency of 1.8GHz and 2GB of memory to ensure the overall stability of the system;
3. Remote monitoring of online, working, and abnormal status of terminals in the jurisdiction
4. Equipped with a built-in 3W speaker, it can achieve remote two-way visual intercom, monitoring, whole area broadcasting, and timed playback of background music;
5. Built in SD card, capable of downloading and storing intercom records;
6. Equipped with a built-in 2-megapixel camera, it can display exquisite image quality during meetings and calls, and supports H.264 encoding;
7. Compatible with standard SIP protocol, can be separately connected to VOIP telephone system (supports mainstream IP-PBX);
8. Support audio and video multi-party streamlined conference calls, with a maximum support of 40 participants;
9. Support environment monitoring and loop monitoring to view terminal status;
10. Remote playback and download all intercom terminal call recordings and videos;
11. Supports wired and WiFi network access, and supports cross network segment and cross routing.
Network communication protocol: TCP UDP RTP SIP
Network chip speed: 10/100Mbps
Audio sampling, bit rate: 8kHz~44.1kHz, 16 bits, 8Kbps~320Kbps
Camera: Built in 2 million camera
Display screen and resolution: 10.1-inch high-definition IPS LCD touch screen, resolution 1280 * 720
Interface:
Network: 1 RJ45 Ethernet port
Audio: 1 audio input and 1 audio output
Power supply: 1 power port
HDMI: 1 HDMI interface
USB: 1 USB interface
SD card: Standard SD card interface
Shell protection level: The shell protection of the sample meets the IP20 level requirements in GB/T 4208-2008
Power supply and power consumption: DC 12V ≤ 20W
Working environment: Temperature range of -10 ℃ to 60 ℃
Size: 300 × 184 × 65mm (length × width × height)
Note: Please refer to the product design for detailed product parameters. Any changes will not be notified separately
